Elite - Model TSHVC15 -Horizontal Vacuum Tube Furnace
The TSHVC15 is a Horizontal tube furnace with integral vacuum equipment for low vacuum use with an ultimate vacuum level 10 ¯5 mbar nominal. Top grade silicon carbide rods mounted parallel with and equispaced around the furnace tube.
Most popular related searches
vacuum tube furnace
tube furnace
vacuum furnace
turbo molecular pump
furnace
gas safety system
pirani gauge
water cooling
safety system
rotary vane pump
- Vacuum vessel - ceramic tube with SS end seals.
- Rotary Pump - two stage sliding vane pump
- Water cooled oil diffusion pump or turbo molecular pump
- Backing/roughing & baffle valve (manual)
- Pirani gauge - Low vacuum monitoring
- Penning gauge - high vacuum monitoring
- Thermocouples, type R, one for control and one for overtemperature protection.
- 3 zone control
- Semi/fully automatic vacuum and heating cycles.
- Low vacuum systems
- Gas control/safety systems
- Gas inlets
