ETS - Model Bio-F -Organic Compact Biofilter System

ETS carries out design, fabrication, installation and commissioning of it`s organic media packaged BIO-F biofilter systems. Suitable for low to medium air flows (100 - 2,600m3/hr) and low H2S concentrations (1-10ppm average/10-40ppm peak concentrations), the BIO-F biofilters is well suited to small wastewater treatment plants and pump station applications. The BIO-F biofilter is based on the principal of immobilised fixed film microbiological technology where-by select bacteria are able to utilise contaminants in the air stream as a part of their energy pathway. A combination of Diffusion, Disassociation and Oxidation result in H2S being converted to Sulphate and Hydrogen.
