Tiger-Vac - Model SS-15 to 55 (TC) TE Series -Explosion Proof and Industrial Vacuum Systems
FromTiger-Vac Inc.
Tiger-Vac Inc. specializes in the design and manufacture of advanced vacuum systems tailored for hazardous locations as defined by the National Electrical Code (NFPA 70). Their products, such as the Megaton and Planet series, are engineered to safely recover combustible, conductive dusts, and flammable liquids. These vacuum systems are ESD safe, preventing electrostatic discharges and comply with NFPA 77 standards on static electricity management. Suitable for Division 1, Class I and II environments, they are certified with specifications like Ex h IIC T6 Gb and Ex h IIIC T85°C Db. The vacuums are versatile with applications ranging from 3D printing, food, and pharma processing, to heavy-duty industrial uses like welding fume extraction and combustible housekeeping. Additionally, they address specific needs such as cleanroom compatibilities and nuclear containment, ensuring comprehensive solutions across varied industries.Most popular related searches
industrial vacuum
activated carbon cartridge
welding fume extraction
static electricity
dust ignition
hazardous area
combustible dust
fume extraction
activated carbon
solvent recycling
Certifications
ATEX 3rd Party Certified
Logo-CELogo-EX II 2GD
Ex h IIC T6 Gb
Ex h IIIC T85°C Db
LCIE 03 ATEX 6310 X
Ex h IIC T6 Gb
Ex h IIIC T85°C Db
IECEx LCIE 17.0076 X
GUARANTEED for the Safe Recovery of Combustible/Conductive Dusts and Flammable Liquids
ESD Safe Vacuum System designed to prevent Electrostatic Discharges (ESD)
II 1/2 GD
External : Ex h IIC T6 Gb Ex h IIIC T85°C Db
Internal : Ex h IIC T6 Ga Ex h IIIC T50°C Da -4°C ≤ Ta ≤ +40°C
EN 17348 LC – Flammable and non-flammable liquids collection
- Legally certified explosion proof/dust ignition proof
- Less than 10 ohms of resistivity
- Available with an optional activated carbon cartridge for the adsorption of toxic/noxious fumes and vapors
- Designed for aircraft de-fueling and de-puddling
- Pneumatic (air-operated). Single venturi, or twin venturi for more power
- For liquid recovery
- All stainless steel Type 304 construction (except cart)
- With red & yellow bands
- Mounted on a Tilting Cart (TC) for easy disposal of recovered materials
