F&J - Model VFD Series -PC Interfaceable Multi-Sensor Air Flow Calibrator
Notable Features: One Calibrator: Multiple Flow Sensors. Vacuum Fluorescent Display (4 lines×24 characters). 4 button key pad for stand alone operation. Mass flow or Volumetric flow. Volume Totalization Feature. Operator selectable Reference T and P. Operator selectable engineering units. Multi gas option. ± 1.0% Full Scale (F.S.) Accuracy. User customizable calibration report. Semi-Automatic calibration-verification when used with F&J digital air samplers. PC Interface program: Western or Asian languages. Two Year Warranty. Complimentary Storage Case.
Most popular related searches
air flow calibration
flow calibration
flow sensor
digital air sampling
differential pressure sensor
barometric pressure
mass flow
multi-gas
pressure sensor
air sampling
MEASUREMENT PRINCIPLE
- Flow Sensor: Differential Pressure Sensor
- Standardization: Operator selectable values for reference temperature and pressure
- Flow Curve linearization: Individually calibrated and software corrected
MEASUREMENT RANGES
- Air flow: Various flow ranges available
- Temperature: -40º - 122º F (-40º - 50º C)
- Barometric pressure: 30 - 22 In-Hg (760 - 559 mm-Hg); (101.325-74.5 kPa)
- approx. Sea level to 5900 ft. (1800 m) elevation above sea level
- Optional low range to 10 In-Hg (254 mg) (33.86 kPa)
MEASUREMENT ACCURACY
- Air flow: ± 1.0% of full scale
- Temperature (Typical): + 1ºC over range –20ºC to 50ºC
- Barometric pressure: ± 1% of reading over measurement range of 22.00-30.00 “Hg
STANDARD TEMPERATURE and PRESSURE CHOICES:
- Temperature 32ºF (0ºC) 59ºF (15.0ºC) 68ºF (20.0ºC) 70ºF (21.1ºC) 77ºF (25.0ºC)
- Pressure 29.92”Hg (1 atm, 760mm Hg, 1.013 bar, 101.325 kPa)
- 1 bar, (100kPa, 750mm Hg, 0.987 atm 29.53”Hg)
