Curtiss-Wright - Model FOR-CC-850-MM -Fiber Optic Receiver

Module type: Receiver. Optical mode: Multi-mode. Optical wavelength: 850nm.

Most popular related searches

Input/output: Form-C relay output
Optical connector type: ST
Power: 24Vdc at 50mA
Optical dynamic range: 30dB into 200/230μm fiber, 18dB into 62.5/125μm fiber
Relay contact rating (FOR-CC): Maximum switching voltage 100Vdc, 250VAC, 5A at 30Vdc, 10A at
125VAC, 6A at 277VAC (resistive load)
Connections: Cage-clamp screw terminals, 12-24 AWG (0.5-2.4mm)
Indicators: Green LED, power, closed contacts
Input (FOT-CC): Dry contacts, 10 ohms maximum contact resistance
Ambient conditions: -40 to 85°C operational, 0-95% relative humidity, non-condensing
Weight: <5oz (140g)

Technical Specification
