Curtiss-Wright - Model FOT-CC-850-MM -Fiber Optic Transmitter

Feature: Description

• Input/output: Input
• Optical connector type: ST
• Power: 24Vdc at 50mA
• Optical dynamic range: 30dB into 200/230μm fiber, 18dB into 62.5/125μm fiber
• Relay contact rating (FOR-CC): Maximum switching voltage 100Vdc, 250VAC, 5A at 30Vdc, 10A at
• 125VAC, 6A at 277VAC (resistive load)
• Connections: Cage-clamp screw terminals, 12-24 AWG (0.5-2.4mm)
• Indicators: Green LED, power, closed contacts
• Input (FOT-CC): Dry contacts, 10 ohms maximum contact resistance
• Ambient conditions: -40 to 85°C operational, 0-95% relative humidity, non-condensing
• Weight: <5oz (140g)
• Accessory: Power supply (PSM-CC)
