Fiberdur - Model CSVE 16/10 -filament-Wound Pipes

Fiberdur filament-wound pipes “Fiberdur CSVE 16/10” are manufactured from Vinylester with a special chemical protection layer. They are available in the standard product range with nominal diameters of 25-1200 mm for pressures 16 and 10 bar (nominal pressure). Nominal diameters up to 2000 mm are available on request. CSVE pipes are hotcured in a curing station at a temperature of more than 90°C. This curing results in a thorough impregnation of the elementary fibres. Production lengths of the pipes are approx. 6 m for DN 25-80, 10 m for DN 100 and larger.
