Cytiva - Model SolVac -Filter Holder

Supor™ filter holder, a Pall Life Sciences product, features a versatile design that fits most HPLC bottles, flasks, and containers, and eliminates the added steps of washing flasks and transferring mobile phase solvent from flask to reservoir.

• Versatile design fits most HPLC bottles, flasks, and containers, and eliminates the added steps of washing flasks and transferring mobile phase solvent from flask to reservoir.
• Draws directly from HPLC solvent bottle. Less likely to spill aggressive solvents than glass funnels or disposable cups.
• Durable plastic construction is less likely to break than glass funnels, assemblies, or adapters.
• Patented magnetic seal is reliable and leak proof. Eliminates the possibility of membrane shifting or tearing which can occur with aluminum clamps or threaded holders.
• Reusable, chemically resistant polypropylene construction is resistant to common HPLC mobile phase solvents such as methanol, acetonitrile, and tetrahydrofuran.

Specifications Materials of Construction

• Upper Housing, Housing Base: Polypropylene
• Feedline Tubing: Ultra chemical-resistant Tygon*, 4.8 mm (3/16 in.) ID
• Thumb Clamp: Celcon*
• Feedline Sinker: PTFE
• Vacuum Port Adapter, Membrane Seal Gasket, and Seal Gasket: Polyethylene

Effective Filtration Area

• 10.2 cm²

Filter Size

• Accepts 47 mm filter

Inlet/Outlet Connections

• Tapered inlet accepts 3.2-6.4 mm (1/8-1/4 in.) ID tubing; outlet seals to bottles with openings 17.8 mm (0.7 in.) ID to 48.3 mm (1.9 in.) OD

Vacuum Port Adapter

• 4.8-7.9 mm (3/16 - 5/16 in.) tapered hose barb

Maximum Vacuum

• 63.5 cm Hg (25 in. Hg)

Operating Temperature

• Ambient; not to exceed 38° C (100° F); not autoclavable

Chemical Compatibility

• For detailed information about chemical compatibility by membrane type, see the Chemical Compatibility Chart.

Applications

• Remove contaminating particulate from mobile phase or other solutions
• De-gas mobile phase solvents and solutions
• Eliminate pour-and-wait filtration
• Remove microbial growth every 24 hours from aqueous buffer mobile phases

• Parameter: SolVac™ Filter Holder - (1/pkg)
• Effective Filtration Area : 10.2 cm²
