Space-Saver - Model SX -Filtration Systems

Compact / high flow filtration / carbon or resin purification. Material: CPVC, PP, PVDF. Performance: 600 - 1200 gph.

Most popular related searches

The SERFILCO Space-Saver `SX` Series is engineered to provide reliable, high performance filtration in a small package.
These compact pump and filter systems are popular for use on small to medium size tank production in the electronics industry and in precious metal plating.
Featuring SERFILCO`s new, non-metallic, leakproof Series `X` magnetic coupled pumps and industry proven Series `S` filter chambers, these systems provide high flow and high turnover rates, assuring continuous particle removal. Space-Saver `SX` systems are available with or without a carbon or resin purification chamber.

Seal-less magnetic drive pumps
Space-Saver `SX` filtration systems feature highly efficient seal-less magnetic coupled pumps for total solution containment and reliable performance. The pumps are available in PP or ETFE.
Filter chamber
Constructed of PVC, CPVC, PP or PVDF to ensure chemical and temperature
compatibility in a wide range of applications.The standard chamber accepts double open end (DOE) depth wound, pleated, melt blown, cleanable sleeve and carbon cartridges. A 222 "O"-ring seat for single open end (SOE) cartridges is optional.
Simple carbon or resin treatment
Space-Saver `SX` systems are also available with optional purification chambers in PVC or CPVC with reusable ABS canister offering a low-cost, but effective method of continuously or periodically removing organic impurities from plating baths and other chemical solutions.

Features
