DDI SuperFlex - Fine Bubble Disc Diffusers
FromDDI SuperFlex
SuperFlex disc diffuser units are available with premium quality EPDM membranes. The diffusers incorporate an external triple-check valve design to prevent intrusion of liquid or solids into the diffuser or air piping under normal on/off operating conditions.
Most popular related searches
disc diffuser
EPDM membrane
aeration diffuser
check valve
EPDM membrane diffuser
fine bubble diffuser
membrane diffuser
disc fine bubble diffuser
bubble diffuser
membrane disc diffuser
- Base and ring are constructed of glass-filled polypropylene.
- Base unit connection is 3/4-inch male NPT.
- Standard disc diffuser membranes are EPDM.
The 9-inch and 12-inch diameter diffusers employ a 3/4-inch diameter NPT (male) threaded connection for ease of installation/maintenance and universal application. Units can be mounted using the universal diffuser mount and are also available with Saddle Mount configuration (as shown), which provides unmatched mechanical strength.
