4Matic - Model 4M-DF-ECO -Flanged End Butterfly Valve
“4Matic” offers Manual (Gear / Handle) Flanged End Butterfly Valve, engineered for multiple ON/OFF operations in the larger pipe line and full flow down streams. Size Range : 3″ to 48″.
Most popular related searches
butterfly valve
flanged butterfly valve
butterfly valve centric
centric butterfly valve
pipe lining
water hammer
gaskets
water surge
- Integrally moulded seat liner on the body, which ensures excellent dimensional stability & guaranteed seat tightness.
- Seat liner extending on to the contact faces ensures perfect sealing and eliminates the need for separate flange gaskets.
- Narrow land disc ensures perfect sealing with least operating torque requirements.
- A fully universal body design ensures fitting of the valve between companion flanges of all popular standards (viz : ANSI, BS, DIN,JIS, IS etc.)
- The notch disc & band lever ensures locking of the valve in 8 intermediate position in addition to close and open position. Hand lever can be locked through pad lock.
- Body casting made of superior FG 260 grade cast iron to ensure additional strength.
- Valve disc made of stainless steel / ductile cast iron which enable protection against possible water hammer or pressure surges.
- A truly line size body bone to ensure maximum flow capacity with the lowest pressure drop.
