Huber+Suhner - Model 50 Ohm, 1 GHz, 205°C, ø1.25 mm, PFA jacket -Flexible Coaxial Cables

General Information

• Product code: K_01152-07
• Cable family: K: RF cables with PTFE/FEP/PFA dielectrics
• Available as assembly only: No
• Cable group: U0

Electrical data

• Impedance: 50 Ω +/-5Ω
• Operating frequency: ≤ 1 GHz
• Capacitance: 96.6 pF/m
• Velocity of signal propagation: 69 %
• Signal delay: 4.83 ns/m
• Screening effectiveness: 40 dB at frequency 0.001 GHz ... 1GHz
• Insulation resistance: 100000000 MΩ*m
• Operating Voltage (at sea level): ≤ 0.4 kVrms
• Test voltage (50 Hz/1 min): ≤ 0.8 kVrms

Mechanical data

• Weight: approx. 9 g/m
• Static bending radius: ≥ 6 mm
• Repeated bending radius: 12 mm
• Dynamic bending radius: < 20 mm

Environmental data

• Operation temperature: -80 °C ... 205 °C
• Installation temperature: -20 °C ... 60 °C
• Flame propagation standard: IEC 60332-3
• UL (horizontal flame test)
• Fire characteristics: contains halogene
• Material compliance ROHS
• Directive: RoHS 2011/65/EU and (EU) 2015/863
• Rating: Compliant without exemption

Material compliance REACH

• Regulation: REACH 1907/2006 Article 33 SVHC
• Rating: Free of SVHC >0,1%
