HYMEDI MACHINERY - Model CSF50 -Forklift with Integrated Safety and Ergonomic Features

The Forklift from HYMEDI MACHINERY is engineered for robust performance in industrial applications. It is equipped with two engine options: Isuzu 6BG1QC-02 delivering 82.5 kW and WP4.1G125E302 offering 92 kW. Weighing 8400 kg, this forklift boasts a load capacity of 5000 kg with a load barycenter distance of 600 mm. The wheelbase spans 2250 mm, supporting both super elastic and pneumatic tire configurations sized at 8.25-15-14PR for both front and rear. Enhanced safety features include wide-angle rear mirrors for better rear visibility and a built-in fuel filler lock enhancing fuel security. Ergonomic design elements like an all-aluminum radiator improve cooling efficiency, while an under-engine hood power cut-off switch extends battery life and enhances safety. Serviceability is bolstered by enlarged thermo vents increasing cooling area by 20%, and integrated joints according to ISO standards reduce oil leakage by 99% and extend the equipment's lifespan by three times.
