External Gear Pump
Type : External Gear
Temperature : Up to 180 degree C
Material of pump construction
Casing : Cast iron, SS304, SS316
Gear : Cast iron, SS304, SS316
Shaft : Steel, hardened, SS304, SS316
Shaft sealing : Mechanical seal or packing seal
Suitable for : Liquid with viscosity up to 1,000 cps
: Lubricating oil, Hydraulic Oil, Dirty Oil
Internal Gear Pump
Type : Internal Gear
Temperature : Up to 180 degree C
Material of pump construction
Casing : Cast iron, SS304, SS316
Gear : Cast iron, SS304, SS316
Shaft : Steel, hardened, SS304, SS316
Shaft sealing : Mechanical seal or packing seal
Suitable for : Liquid with viscosity up to 100,000 cps
: Lubricating oil, Hydraulic Oil, Dirty Oil, Molasses, liquid sugar, chocolate, Paint, Asphalt
