HCP - Model AF Series -Submersible Sewage / Wastewater Pumps
The AF Series, a selection of submersible sewage and wastewater pumps, is notable for its high performance and robust design suitable for residential, industrial, and municipal applications. These pumps are designed with various impellers like vortex, open, and channel impellers to handle solid waste, slurry, and fibrous materials without clogging. Key features include a cast iron body with an epoxy coating, Triangular handle design for easy handling in guide rail systems, an Oil Elevation Disk to maintain seal lubrication, enhancing service life, and eco-friendly lubricants ensuring a toxic-free environment. Covering power options from 0.5 to 75 HP and available in both 50Hz and 60Hz versions, these pumps are engineered to operate efficiently across a broad range of conditions.
- Pump body is made of cast iron and with high solids epoxy coating which offers the highest quality and performance.
- Triangular handle is designed for easy handling on Guide Rail System (model above 5HP).
- Oil Elevation Disk design in the oil chamber to ensure the mechanical seals lubrication and to extend the service life of pump.
- Eco-friendly Food Grade Lubricant to keep wastewater applications a toxic free environment.
- Non-clogging impeller designs :
U Type Vortex Impeller：U type non-clogging impeller produces a vortex (whirlpool effect) which allows slurry, long fibrous materials and solid waste to pass through, without contact with the impeller.
P Type Open Impeller：P type impeller is open and comes with one or two vanes. The impeller is excellent to use for waste materials to prevent clogging.
E Type Channel Impeller：Enclosed channel impeller features high efficiency, large capacity, large solid passage and non-clogging.
- Residential buildings, hospitals, commercial buildings and household usages.
- Livestock farming, pig farming, dairy farming and sewage treatment.
- Food industry, pulp and paper industry, mining, dyeing and finishing factory, leather factory, steel manufacturer, electronics industry and wastewater treatment.
- Hydraulic engineering and flood control.
- Sanitary sewer pumping.
