HCP Pump Manufacturer Co., ltd. products
HCP - Model AF Series - Submersible Sewage / Wastewater Pumps
The AF Series, a selection of submersible sewage and wastewater pumps, is notable for its high performance and robust design suitable for residential, industrial, and municipal applications. These pumps are designed with various impellers like vortex, open, and channel impellers to handle solid waste, slurry, and fibrous materials without clogging. Key features include a cast iron body with an epoxy coating, Triangular handle design for easy handling in guide rail systems, an Oil Elevation Disk to maintain seal lubrication, enhancing service life, and eco-friendly lubricants ensuring a toxic-free environment. Covering power options from 0.5 to 75 HP and available in both 50Hz and 60Hz versions, these pumps are engineered to operate efficiently across a broad range of conditions.
HCP - Model F/FN Series - Submersible Sewage / Effluent Pumps
The F/FN Series of submersible sewage and effluent pumps by HCP feature state-of-the-art designs made to handle wastewater efficiently. These pumps come equipped with U/P and V type impellers designed for diverse operating ranges in wastewater applications. Key features include the F/FN UL Type Non-clog models capable of passing larger solids and the lightweight, portable V Type for easy installation. Each pump incorporates IP68 level motors tested to ensure the highest quality. The inclusion of Oil Elevation Disk systems in the oil chamber maximizes mechanical seal lubrication, thereby enhancing pump longevity. Standard accessories include a water-resistant, epoxy resin sealed cable base, Auto-cut Protector, double mechanical seals, and food-grade lubricant.
HCP - Model AFC Series - Submersible Cutter Pumps
The AFC Series Submersible Cutter Pumps from HCP are designed for effective wastewater management and sewage disposal. Featuring a tungsten carbide edged impeller, these pumps efficiently handle sewage and break or tear debris, making them suitable for heavy-duty applications. Key specifications include a motor frequency of 50Hz or 60Hz, motor rotational speeds of 3000rpm for 2-pole and 1500rpm for 4-pole configurations, and thermal class insulation of F for engines between 2 to 5 HP and H for engines from 7.5 to 15 HP. In terms of durability, the pumps come with a class IP68 protection rating, double mechanical seals, and are crafted from heavy-duty casted iron with high solids epoxy coating.
HCP - Model AL Series - Submersible Wastewater / Effluent Pumps
The AL Series by HCP comprises rugged cast iron submersible pumps designed for handling wastewater and effluent with a high solids epoxy coating and offering exceptional performance and reliability. These pumps feature a 5~15HP motor with a unique triangular handle for easy installation and transportation in guide rail systems. Designed for compact spaces, they offer high head and optimal efficiency across a broad range of applications. Notably, the oil elevation disk within the oil chamber helps maintain lubrication of the mechanical seals, significantly extending pump life. Additional functionalities include an Auto-cut protector, dual mechanical seals with a lip seal design, and a robust epoxy treatment on the cable base.
