Geometics - Model GeoEel -High Resolution 2D Seismic Survey

The smallest-diameter solid design available (only 44.5 mm), the GeoEel Solid™ is easy to deploy, easy to transport and can be shipped by air.

Separate 8-channel modules coupled with a unique slim active section design yield ultra-low towing noise levels (under 4 microbar) and are largely immune to electronic interference, leakage and ground loops that plague analogue streamers.

Communicates via 100 mbs Ethernet to the Geometrics CNT-2 controller, running field-proven software that is used on over 70 installations worldwide.

Advantages of solid streams

• No bulge wave transmission along the length of the streamer.
• Up to 6 hydrophones per group.
• Offers higher resolution compared to competitors streamers due to the tight hydrophone group spacing.
• Low noise compared to fluid filled streamers.
• Extremely rugged and easy to handle.
• Environmentally friendly and non-flammable. Manufactured from solid polyurethane the GeoEel SolidTM presents no risk of leaking oil and can be shipped via air-freight.
