Homogenising - High Shear Laboratory Homogenizer
Highly versatile, with repeatable results, pressure and temperature control. Process volumes to 275ml per minute / 16 L per hour and a wide range of sample sizes from 1m to 35ml. Improved processing efficiency for multiple applications - Cell Lysis, Protein Purification, Particle size reduction, Liposome preparation, Nanoemulsions and Dispersions. Controllable pressures up to 60,000 psi (410 MPa). Multiple sample sizes. Flow rates from 1ml to 275ml per minute / 16 L per hour. Easy to use.
Most popular related searches
particle size reduction
laboratory homogenizer
particle sizing
size reduction
digital temperature controller
laboratory homogenization
pressure and volume controller
sample processing
autoclave
nanoparticle
- Continuously adjustable process pressure from 1,500 psi (10 MPa) to 60,000 psi (410 MPa) allows processing of ingredients that are difficult to process in any other way, offering the widest scope of formulations.
- Can be run in continuous mode or single-shot mode - including viscous formulations. The flow rate in both modes is adjustable from drop-by drop to 275ml per minute.
- Multiple options for temperture control - cooling or heating - during either pre-processing or post processing.
- Choice of (easily interchangeable) processing cells: 1 ml, 10 ml, 18 ml and 35 ml.
- The homogenising valve features ceramic needle and seat with profiled geometry for optimal performance.
- Operating parts are easy to remove (without tools) in a very short time for cleaning, sterilization (including autoclave), pre-cooling, or pre-warming, all as required by the sample or process.
- Cell Lysis - Disruption.
- Particle Size Reduction.
- Nanoemulsions / Microemulsions.
- Lipid Nanoparticles - LNP`s and SLN`s.
- Liposomes preparation.
- Protein Purification.
- Dispersions.
- Suspensions.
(basic configuration)
- Width approx. 550mm (21.7″)
- Depth approx. 600mm (23.6″)
- Height approx. 670mm (26.7″)
- Weight approx. 125 kg (275 lb)
