VIEW Metrology System - Model Benchmark 450 -High-Value High-Accuracy Dimensional Measurement

The VIEW Benchmark 450 delivers high performance with generous measuring envelopes. The system’s stage handles large form-factor parts with high precision in a rugged, shop-floor configuration with a small footprint. Its fixed bridge design separates the X and Y axis motions, allowing each to operate without any influence on the other. This arrangement provides the maximum mechanical integrity and accuracy in the stage motion. Benchmark 450 and VIEW metrology systems are ideal for measuring flat 2D parts with very tight tolerances. Ideal industry applications include semiconductors, microelectronics, aerospace, medical devices, small machined parts, and other parts requiring automated non-contact measurement.
