TDS - Model 3000 Series -High Volume Trench Drain System

The 3000 Series™ is a high volume trench drain system designed for highway traffic and airport applications. The chemically resistant fiberglass channels allow up to 3,000 GPM of water with proper installation and slope; drainage channels are available with a 1% slope. For special situations, .5%, .75% and 1.25% slopes can be ordered to suit a range of site conditions. The 3000 Series™ channels come in 8 feet lengths with integral stainless steel or zinc-plated steel frames to add durability.  Lightweight channels allow for quick installation. The 3000 Series™ drain can maintain a continuous slope up to 240 feet.  End and bottom outlet adapters connect the drain system to standard 8″ PVC piping.
