Amarinth - Model ISO 5199 Type 1 & 2-C Series -Horizontal Chemical Process Pumps

Using modern computer aided design software the pumps are designed as a heavy duty, minimal wear, long life pump. Conceived as a modular design, with a number of options available, ensures full compliance with a customer`s exact requirements and specifications. A heavy duty baseplate helps achieve low vibration and noise levels which in turn extends the pump`s life and ensures maximum running time.

The pumps can be fitted with a variety of proprietary components (i.e. seals, motors and couplings) from all the major manufacturers to cater for customers site preferences. Pumps using double mechanical seal arrangements can be fitted with a seal support system attached. This can be supplied by Protect System, which is designed and manufactured by Amarinth, or another manufacturer`s seal support system can be fitted.

To complete the package a full range of standard material options from cast iron and stainless steel, to super duplex and hastelloy are available to match your process fluid. NACE and NORSOK compliant materials are also available. Standard documentation packs including manufacturing data books, material certification, installation and operating manuals are available to suit the application. Performance testing to BS EN 25199 / ISO 5199 and various NDE (non destructive examination) and NDT (non destructive testing) options are offered to ensure full compliance to our customer`s specifications. Alternative bespoke packages can be tailored to fit your exact requirements.

Hydraulic Performance

Amarinth C Series pumps can be fitted with fixed or variable speed drivers from any manufacturer. The overall C Series hydraulic coverage chart is shown on the left. More detailed hydrualic coverage charts list individual pump designations at 2 pole & 4 pole speeds. Specific duty curves will be provided with all quotations.

Use the slider at the bottom of the images to select the hydraulic coverage chart you`re interested in & then launch the relevant pdf to review the coverage charts in more detail.

Drawings

A number of images in various pump configurations are provided to help you visualise our A Series product including:

• Isometric view
• Exploded view
• General arrangement
• Sectional arrangement

Select an image below using the slider at the bottom and then launch the relevant PDF.
