Technomax Microklin - Automatic Self-Cleaning Disc Filter

Technomax’s distinctively developed disc filtration technology operates using thin, color coded polypropylene discs of a specific micron rating. The discs are diagonally grooved on both sides, in opposite directions. A series of discs are stacked and compressed on a specially designed spine. The stacked discs are enclosed in a corrosion proof and pressure resistant housing. The grooves of any two adjacent discs, pressed together, create a series of crossing points which form multiple particle traps. In the filtration process, the force of the spring along with the differential pressure firmly compresses these discs together providing exceptional filtration effciency. Filtration occurs as water percolates from the outer diameter to the inner diameter of the filter element. Depending on the micron rating, there are multiple crossing points in each track, creating distinctive in-depth filtration.
