Michell - Model OptiCal -Humidity and Temperature Probe Calibrator
The OptiCal is a premium, self-contained calibrator for humidity sensors. It features an integrated chilled-mirror reference which enables the operator to perform calibrations that are traceable to national standards. The calibration chamber accommodates up to 5 probes or sensors of any brand or model. The chamber is insulated, and temperature controlled for maximum stability and minimum temperature gradients.Most popular related searches
humidity calibration
relative humidity calibrator
relative humidity sensor
digital temperature controller
humidity sensor
calibration instrument
humidity generator
temperature probe
humidity temperature probe
humidity chamber
- Simple operation and maintenance
- Easy calibration of relative humidity sensors
- Excellent chamber stability and uniformity
- Manual control or optional straightforward automated set point programming
- Optional in-built data-logging for reference probe and probes under calibration
- Humidity and temperature-controlled chamber
- Generate 10 to 90% RH over +10 to +50°C temperature
- Transportable to allow on-site calibrations
Humidity
- Generation Range 10-90% RH
- Accuracy
- Control Element ≤±1% RH (10–70% RH)
- ≤±1.5% RH (70–90% RH)
- Stability ±0.2% RH (20–80% RH)
Temperature
- Generation Range +10 to +50°C
- (Lowest T set point = 10°C below ambient)
- Accuracy ±0.1°C
Suitable Applications
- On-site or in-lab verifications
- Validation of RH probes at pharmaceutical manufacturing facilities
- Validation of RH probes at meteorological offices
- Validation of RH probes in food manufacturing
