Hydraulic Diaphragm Pump

From

0

Performance conforms to API 675.Glandless design and entirely Leak Proof operation.Integrated Pressure Relief Valve.Diaphragm is always balanced between the pressure exerted by the hydraulic oil and liquid to be dosed. Longer Diaphragm Life.Automatic air bleeding from the hydraulic oil ensures better metering accuracy.Manual stroke adjustment by eccentric.

  • Multiple Head with identical or different outputs for each head using single drive.
  • Jacketed Head for Heating or Cooling the liquid been pumped.
  • Automatic flow variation by receiving 4-20 mA signal from the process.

  • SS304/ SS304L
  • SS316/ SS316L
  • Carbon Steels
  • PP
  • PTFE
  • PVC
  • PVDF
  • Alloy20
  • Hastalloy
  • Any other special alloy.

  • Oil & Gas
  • Petrochemicals
  • Power
  • Chemicals and Fertilizers
  • Water, Waste Water, Sewage Treatments
  • Pharmaceuticals
  • Paper and Textiles
  • Food and Beverages
