BSP-TEX - Model LX -Hydraulic Piling Hammer
The LX hydraulic hammer range of powerful yet lightweight hammers have been designed to provide greater stability to piling rigs. The LX hammers provide an economical solution for the installation of all types of piles. The four hammers, LX30, LX40, LX50 and LX60 in the range are capable of driving steel, concrete or timber piles in a variety of soil conditions. Drop-weights extend from 2.5t up to 7t while impact energy ranges from 20kNm up to 55kNm.
Major features include total control of hammer stroke and blow rate; precise matching of energy to suit the pile driving requirements while a highly efficient hydraulic system reduces energy loss and maintains a low running cost. The Hydraulic cylinder is BSP’s own designed and developed system.
- Total control of hammer
- Designed for easy maintenance
- Short overall length
- Optimum power to weight ratio
- Can operate from BSP Power pack or from hydraulic piling rigs or cranes
- A range of standard drive caps and pile helmets are available
- The hammers are fitted with a single acting hydraulic cylinder system to give an equivalent stroke of 800mm
