BSP-TEX - Model CXL -Hydraulic Piling Hammer
CXL hydraulic piling hammers are designed for driving sheet piles, tube and H-piles, concrete piles, combiwall and wooden piles. Available with legs and inserts or tube pile guides for use freely suspended, or with back guides for operating from a hydraulic piling rig or leaders. CXL hammers are capable of driving steel or concrete piles to an ultimate load bearing capacity of up to 11000kN. Features include total control of hammer stroke and blow rate, precise matching of energy to suit the pile driving requirements. In addition, changing the drive cap dolly is quick and easy.
CXL hammers can be operated directly from a hydraulic rig or used with a BSP-TEX power pack. The cylinder and drop-weight connection with shock absorbers are readily accessible and easy to maintain.
The cylinder design is unique to BSP-TEX hammers, and offers superior performance. The hydraulic system is efficient, economical and reliable. Optional equipment includes a digital readout of hammer performance in a choice of units (stroke or energy) and are also available with BSP-TEX Hydropacks which conform with current emissions regulations.
- Total control of hammer stroke and blow rate
- Allows precise matching of energy to suit the pile driving requirements
- Highly efficient hydraulic system delivers low energy loss and low running cost
- Simple, fast dolley changing
- Low maintenace and easily accessible
- Available with BSP Hydropacks for optimum hammer performance
- Can be operated directly from hydraulic crane
