BSP-TEX - Model CG -Hydraulic Piling Hammer
All the CG piling hammers are designed for driving a variety of bearing piles including steel tube, combipiles, H-sections, raked/batter piles and reinforced/prestressed concrete piles and can be operated from piling rig leaders or crane suspended.
Important features of the CG range include total control of hammer stroke and blow rate, and precise matching of energy to suit the relevant pile driving requirements. These large-capacity hammers are capable of driving piles with an ultimate load bearing of up to 23,700kN.
Drive cap dolly changing is quick and easy, and cylinder and drop-weight connection with shock absorber is easily accessible for routine maintenance.
CG hammers are economical to operate because they have a low hydraulic power requirement. For optimal performance, use CG hammers with BSP-TEX Hydropacks.
- Total control of hammer stroke and blow rate
- Allows precise matching of energy to suit the pile driving requirements
- Simple fast dolley changing
- Cylinder and drop-weight connection with shock absorber, easily accessible
- Economical, ow hydraulic power requirement
- Available with BSP Hydropacks for optimum hammer performance
- Suitable for driving raked (batter) piles
