Aquajet - Model Aqua 450V -Hydrodemolition Cutter Robot
The Aqua Cutter 450V is a high-performance Hydrodemolition robot that combines advanced technology with a compact, electric-powered design. Despite its small footprint, it delivers exceptional power and reach, handling reaction forces up to 1,600N. Its extendable tower system allows for a 4-meter (13.1 ft) reach without support and up to 10 meters (32.8 ft) with tower support, making it the perfect solution for confined spaces and zero-emission environments where larger machines can’t go.
Compact electric power
The Aqua Cutter 450V efficiently cleans and descales rebar without causing microfractures, ensuring structural integrity. Designed for horizontal, vertical, and overhead applications, it offers exceptional reach for diverse Hydrodemolition projects. Its electric-powered design makes it ideal for urban and zero-emission environments. The detachable Power Control Module (PCM) allows safe, remote operation while the crawler navigates confined or hazardous spaces like tunnels and flooded sewer pipes. Fully compatible with the Aqua Rail System 3.0 and a wide range of attachments, the 450V also integrates with high-pressure pumps, including the Ecosilence, and connects to Aquajet’s Ecoclear system for on-site water filtration and recirculation, ensuring environmentally responsible operations.
Extendable tower system
The Aqua Cutter 450V, equipped with an extendable tower system, is the perfect choice for vertical applications in tight spaces such as shafts, high walls, and overhead work, but it is just as efficient in horizontal work. It offers a reach of up to 4 meters (13.1 feet) without support and up to 10 meters (32.8 feet) with support. Its adjustable hoist and tilt function ensure precise positioning of the power head, making it easy to retract, inspect the results, and resume work seamlessly.
Disconnectable PCM
With a disconnectable Power Control Module (PCM), both Aqua Cutter 450 models can reach areas inaccessible to electric-powered equipment. Separating the PCM from the tracked crawler allows them to operate independently via radio control. This keeps the PCM in a safe location while the fully submersible crawler navigates confined or hazardous spaces, such as narrow tunnels or flooded sewer pipes.
- Facts: Aqua Cutter 450V
- Length: 2,17-2,34 m (7,1-7,7 ft)
- Min. width: 0,78 m (2,6 ft)
- Track width: 0,78-1,16 m (2,6-3,8 ft)
- Min. height: 0,99/1,29 m (3,2/4,2 ft)
- Operating height: 4 m (13,1 ft)
- Operating height with top support: 10 m (32,8 ft)
- Side shift stroke: 0,42 m (1,38 ft)
- Side reach: 0,86 m (2,8 ft)
- Lance angle: ±45°
- Max reaction force: 1600 N
- Max roller speed AUTO: 25,0 m/min
- Max track speed AUTO: 15,0 m/min
- Noise level: 55 dB
- Hydraulic pressure (operation): 35-200 bar
- Max hydraulic flow: 46 l/min
- Hydraulic oil tank volume: 48 l
- Motor power: Electric motor, 3 phase, Direct start, 5,5 kW
- Sensors: Absolute
- Control system: Evolution 3.0
