IGEMA - Model Type RBA24 -Float Switch
FromIGEMA GmbH
The float switch can be used as water level controller or limiter for steam generators as per TRD 401, 402 or 602. The float switch according to PED directive 97/23/EEC has the CE-mark no. 0035 of the notified body.Applied rules as per TRD/AD2000 or ASME- Boiler.
Most popular related searches
float switch
water level control
water level controller
drain plug
drain valve
level controller
water control
standpipe
- Material according to DIN or ASME
- Protection as per DIN VDE 0470: IP54
- Process connection: flanges as per DIN or ANSI
- Magnetic switch type M130-K (D-07-D-16324-0)
- Cable gland according to DIN EN 50262: M20x1,5
- Drain plug G ½
- Material according to DIN or ASME
- Protection as per DIN VDE 0470: IP54
- Process connection: flanges as per DIN or ANSI
- Magnetic switch type M130-K (D-07-D-16324-0)
- Cable gland according to DIN EN 50262: M20x1,5
- Drain plug G ½
- The component mark is only valid if shutoff valves are installed between process connection and boiler studs. A drain valve is also required
- The functional test is made by lowering the water level in the standpipe
