IMS - Model I-BOx™ -Biological Odor Control System
The IMS l-BOx™ Series odor control system {Patent Pending) is an advanced two-stage biological system that provides ooint source odor control. The first stage is a biological reactor where bacteria are used to oxidize hydrogen sulfide (H2S) and organic sulfur compounds. The second stage uses activated carbon to remove residual H2S and organic odors.
- Two-Stage Design for Effective H;S and Organic Odor Removal
- Compact Design with Optional Fan Cover
- `Plug & Play" Installation
- Non-Hazardous Biological Process
- 99+% H;S Removal Efficiency
- Quiet & Easy Operation
- Polypropylene Exhaust Fan
- FRP Vessel
- Inorganic Biological Media (Stage 1)
- Activated Carbon Media (Stage 2)
- Fan Cover (Optional)
- Water Panel with Media Irrigation System
- FRP Control Panel
- Integral Nutrient Tank with Nutrient Pump
- Exhaust Stack
The system comprises two distinct process stages: biological stage and adsorption stage. The adsorption stage uses virgin activated carbon. The fan operates continuously, pulling foul air from the process area through the odor control system and discharging clean air to the atmosphere.
Stage 1 is designed to remove hydrogen sulfide (H2S) and volatile organic sulfur compounds by providing an environment promoting the growth of acidophilic, sulfur-oxidizing bacteria (principally Thiobacillus thiooxidans). The first stage media is an inert, porous, mineral material designed to resist compaction and degradation from the acidic sulfates produced by the biological oxidation of hydrogen sulfide. Periodic media irrigation provides moisture for the bacteria, and removes the acidic and biological waste byproducts.
Stage 2 is used to remove any remaining hydrogen sulfide and odorous organic compounds. The second stage media is activated carbon.
- Two-stage odor control process
- Compact, small footprint design
- Easy to operate
- Low pressure drop
- Single-piece construction
- Inert media
- Superior non-corrosive materials
- Pre-assembled & factory tested
- Suitable for outdoor installation
- Fan cover (Optional)
