Inclis - Model DH -Inclinometer Probe

The new inclinometer probe INCUS DH, designed by Solgeo, allows to perform a 3D borehole deviation survey; it is equipped with n. 3 magnetometrk and an n.3 accelerometric sensors. In case of iron casing which makes impossible the right working of the magnetometric sensors, the system is provided with a set of aluminium rod that allows to drive the probe inside the BH. INCLIS-DH is connected to the Pc trough a USB Junction box which provides the power supply and the data transfer. The software Saldino allows an immediate restitution of the results in graphical and numeric form.
