Plexus - Model R-050PWR Series -Industrial Power Monitor Remote Wireless System
The Intelligent Wireless System (IWS) nodes comprise of a range of distributed wireless products from Plexus Controls providing advanced supervisory, control and data acquisition (SCADA) functionality for commercial and industrial applications. With `out the box` auto mesh wireless functionality, IWS nodes can be easily installed at a remote location and connected to standard sensors, supporting 4-20mA, 0-5V, 0-10V, HART, temperature, power factor, pressure and many other interfaces. Either through a direct wireless connection or automatically hopping through a series of repeater IWS nodes, the sensor data is relayed back to the IWS Gateway for termination over Ethernet to the IWS Management Server application providing a web based GUI display, logging and alarm management.
The Remote Termination Unit R-050PWR is a fully integrated, self-contained radio and microcontroller package supporting 3 tracking voltage inputs and 3 tracking current inputs to monitor and report power usage and power factor on single or three phase equipment. Thee R-050PWR is powered using either 24V ac/dc input or a 110V-24V wall adapter (included). The R050PWR has been designed to mount directly onto the steel 3 phase isolator/fuse box, supported by the ½” NPT gland. The enclosure may also be mounted onto a flat surface. The frequency of readings can be changed by the user and values logged and plotted on Plexus Controls Network Management System (NMS) software. Plexus also provided an SQL database package that allows more sophisticated packages to access the data for detailed analysis.
- Next generation distributed, intelligent wireless SCADA system
- 3 x Voltage Transducer tracking input
- True RMS Voltage measurement
- 3 x Current Transducer tracking input
- True RMS Current measurement
- Power factor measurement
- Integrated or external long range antenna
- 24V ac/dc or wall adapter powered
- Mounts on the load isolator box or service fuse panel using a ½” NPT gland (included)
- Reliable & scalable auto mesh wireless
- Multiple systems per site gateway
- Full monitoring, alarming from site gateway and/or central SQL database
Reports:
- True RMS AC Voltage
- True RMS AC Current
- Real Power
- Power Factor
