GX Filtration - Industrial Sieve Bend Screens (DSM Screens)
The Sieve Bend Screen (also known as a DSM screen) is a curved static screen used for separating solids from liquids. It is composed of a curved wedge wire screen panel mounted in a frame with openings perpendicular to the flow. Compared to flat screens, sieve bends have a higher capacity and efficiency due to the gravitational force and the curved profile.
Most popular related searches
sieve bend screen
sieve bend
wedge wire screen panels
wedge wire screen panel
sieve screen
stainless steel flange
wedge wire screen
wedge wire panel
mineral processing
tailings dewatering
- Materials: Grade 304, 316, 316L Stainless Steel.
- Screen Type: V-shaped profile wire (Wedge Wire).
- Operation: Static (No moving parts).
Self-Cleaning
The V-shaped wire design prevents clogging and ensures continuous flow.
High Capacity
Significantly higher throughput than flat vibrating screens of the same size.
Zero Maintenance
No moving parts means no power consumption and minimal wear.
Mineral Processing
Coal, iron ore, and copper tailings dewatering.
Food & Starch
Starch extraction, fruit juice fiber removal.
Wastewater Treatment
Primary solid removal in municipal and industrial plants.
- Slot Size (mm) : 0.2, 0.5, 0.75, 1.0, 1.5, 2.0 (Customizable)
- Profile Wire : 1x2mm, 2x3mm, 3x5mm, etc.
- Support Rod : 2x3mm, 3x5mm, 10x15mm, etc.
- Curvature Radius : 500mm, 1000mm, 1200mm, 2000mm
- Arc Angle : 45°, 60°, 90°, 120°
- Frame Type : Carbon Steel or Stainless Steel (Flanged/Boxed)
