Crowcon - Infra-Red (IR) and UltraViolet (UV) Based Flame Detectors
Crowcon offers a range of infra-red (IR) and ultra-violet (UV) based flame detectors for quickly detecting flames at a distance. Depending on model, this includes a variety of gas and fuel fires including those generated from hydrocarbons, hydrogen, metals, inorganic and hydroxyl sources. The 40/40 series operate in the harshest environmental conditions and are self-contained, stand-alone devices designed for direct connection to control and alarm systems or automatic fire-extinguishing systems.
40/40I Triple IR (IR3) Flame Detector
The 40/40I Triple IR (IR3) Flame Detector detects fuel and gas fires at long distances with the highest immunity to false alarms. The 40/40I IR3 can detect a 1ft2 (0.1 m2) gasoline / heptane pan fire at 215 ft (65 m) in less than 5 seconds.
40/40M Multi IR Flame Detector
The 40/40M Multi IR Flame Detector is specifically designed for detection of hydrocarbon and hydrogen flames. It detects hydrocarbon-based fuel and gas fires at long distances with the highest immunity to false alarms.
- There are two versions of 40/40 Series UV / IR Flame Detectors:
- Model 40/40L (& LB) detects hydrocarbon-based fuel and gas fires, hydroxyl and hydrogen fires, as well as metal and inorganic fires.
- Model 40/40L4 (& L4B) is identical to the 40/40L except that the IR sensor works at a wavelength of 4.5µm and is only suitable for hydrocarbon-based fires.
- The 40/40UV Flame Detector design is the most durable and weather resistant UV flame detector currently on the market.
- The 40/40R Single IR Flame Detector detects hydrocarbon-based fuel and gas fires using advanced flame analysis tools.
The 20/20 range includes Mini IR3 and Mini UV/IR detectors which offer a lower cost, lower power, compact design in a general purpose (non-Ex approved) format. The 20/20MI IR3 is also available as ATEX intrinsically safe approved.
20/20MPIHigh performance, compact Triple IR (IR3) Flame Detector in a lightweight polycarbonate housing, especially suited to indoor applications. It retains all the benefits of IR3 technology - long distance detection (up to 140ft/43m) along with the highest immunity to false alarms.
