Griltex - Model GXP DREN 1200 Plus -Insulation and Drainage Waterproofing Membrane
GXP Dren 1200 Duo is a waterproof membrane extruded from high density polyethylene (HDPE), 1,2 mm thick, thermally joined with polyethylene geotextile made from continuous fibres 140 g/m² on the top side and polypropylene or polyester geotextile 250 gm² on the bottom side.
Most popular related searches
waterproofing membrane
waste collection site
waste collection
polyester geotextile
green roof
drainage capacity
drain channel
landfill mining
drainage layer
waterproofing
Used as:
- An insulation and drainage layer for retaining and foundation walls, bridge abutments, waste dumps, ash collection tanks, floor slabs, tunnels, draining channels, green roofs
- A separation and drainage shield in road, railway and airport foundation constructions
- An increased friction angle between the base and the geocomposite prevents skidding of the geocomposite from slopes under the pressure of the ground
- A layer protecting against mechanical damage of insulation layers
- A draining layer for high loads
- An anti-root layer
- A sealing and degassing layer for:
- rubbish dumps
- waste collection sites
- industrial tanks
- Geocomposite weight: 1500 g/m2
- Compression strength: 1500 kN/m2
- Embossing height: 8 mm
- HDPE membrane thickness: 1200 μm
- HDPE membrane surface mass: 1500 g/m2
- Air volume between textile and membrane: 5,3 l/m2
- Drainage capacity: 2,1 l/m/s
- Width: 4 x 10 m, 4 x 20 m
- Temperature resistance: -40 do +80oC
