IVC - Single Stage Water-Ring Vacuum Pump

SHARE

IVC- Single Stage Watering Vacuum Pumps Develop vacuum of 710 mm of HC at Close Suction Considering 32°C Water Temp., 760 mm of HG ( 1002 mbar } Barometric Pressure and ambient suction Temp of 35 OC with a mean in humidity of 50 %. This Pump Also Use as Liquid Ring Compressor. The Pump Compressed Air ( Gas) Free From Oil and Obtain up to 1.5 Kg /Cm2 Discharge Pressure. Inlet Water and Sucked Air { Gas ) and led into Water Separator. The Air Separate From Water and Air is
takeout to the system.

Most popular related searches
water ring vacuum pump
vacuum pump
industrial vacuum
liquid ring compressor
solvent recycling vacuum
industry solvent recycling
industrial solvent recovery
water pump
industrial crystallizer
barometric pressure
  • Chemical Industry : Solvent recovery, Vacuum Distillation, Filtration, Gas Compression
  • Pharmaceutical Industry: Crystallization(Evaporation), Recreation, Drying, Distillation
  • Power Industry : Turbine Gland Exhausting, Conveying of fly ash, Vacuum Priming, Vacuum Deaeration and condenser initial evacuation (hogging).
  • Sugar Distillery Industries : Vacuum filtration.
  • Plastic Industries: Extrusions, Degassing, drying, & conveying
  • Environmental Industry : Bottle Filling, Vacuum Priming, digester gas compression, waste water disposal.
  • Paper & Pulp Industries :   Process Vacuum, Stock & White Water Deaeration, Head Box Compressor /Vacuum Pump.
  • Packaging Industry: Vacuum packaging, production PET containers.
  • Ceramic Industry : Air Removing.Vacuum Processing.
  • Mining : Some Generic Applications In The Extraction Of Alumina From Bauxite, Copper, Titanium Dioxide, Iron Ore, Phosphate Or Coal, Are As Follows:
  • Completely Reliable Operation.
  • Easy Maintenance.
  • Low Power And Water Consumption.
  • Rugged Construction For Heavy Duty Application.
  • Simple And Trouble Free Operation.
  • Suitable For Low And High Vacuum Applications.
  • No Metallic Contact Inside Pump.
  • Leak Proof Sealing Arrangement Also Possible.
  • Clean & Oil Free Discharge.
  • Compression Takes Place With Small Temperature Rise and Smooth Discharge.
  • Simplicity Of Rotating  Parts Improves Reliability Because Of Pump Simplicity, Can Be Readily Disassembled And Reassembled On Site By End User.
