KTI - Model CCWP -Containerized Water Chiller Plant
KTI containerized water chiller plants are used in the cooling of concrete to provide addition water at 3 - 5 °C. Likewise, KTI chillers are used in the production of food and beverages - to cool processes. For example, drinking water can be brought to the required temperature before bottling. A third area of application is the supply of cooling water to machines.
- Daily output: 56 - 560 m³ per day in a container
- Water outlet temperature: 3 - 5 °C
- Water inlet temperature: 20 - 45 °C
- Refrigerant: Ammonia (NH3), Freon (R404A, R449A, etc.)
- Certification: CE, CSA, UL compliant; others possible
- Compressor: Screw compressor / piston compressor, semi-hermetic / open
- Condenser: water cooled, air cooled
- heat exchanger: Shell and tube evaporator (copper), plate heat exchanger (stainless steel)
- Operating mode: Flooded in pump or gravity mode, dry expansion.
- Power supply: 50 or 60 Hz, special voltage possible
- Engine room: 20-foot / 40-foot container, air-conditioned, optional insulated or frame installation
- Control: Siemens PLC, color touch screen
KTI chillers work equally well due to the use of components proven over many years reliable as well as efficient - even under the most demanding conditions. Water with temperatures between +20 to +45 °C is cooled to 3 - 5 °C. At very high water inlet temperatures, the first stage lowers the water to 35 - 38 °C via the cooling tower. Here, large amounts of energy can already be dissipated merely by using evaporative cooling without expending any significant power.
- Up to a production of 180 m³ cold water per day, KTI chillers are mounted in a 20-foot ISO container, up to a production of 440 m³ cold water in a 40-foot ISO container.
- The evaporative condenser can be integrated directly into the container if required. This creates a very compact plug-and-play solution.
- Of course, the plants can also be built with consistent quality on frames for installation in buildings. This allows us to offer our customers individual solutions.
- The most common fresh water temperatures are +20°C in temperate climates, +30°C in hot regions and +45°C in tropical areas.
- KTI service mentality
- German quality standard
- Enhanced reliability
- Optimized running costs
- Longer life expectancy
- Minimized breakdowns
- 100% spare parts availability
- Permanent service availability
- Onsite training of staff at large construction sites
- Service contracts
- KTI containerized water chiller plants are the most energy-efficient models on the market.
- KTI containerized water chiller plants produce chilled water with Temperatures from 3 - 5 °C.
- KTI containerized water chiller plants cool water even with very high inlet temperatures from 45°C .
- KTI containerized water chiller plants come preinstalled and are taken very quickly in operation .
- KTI containerized water chiller plants are optimal for Water pre-coolingin ice production.
