Landytop - Model LXL1000 -Automatic Stool Analyzer
Testing Mode: Single sample or multiple samples. Sample Tray: Wheel type, 24 sample slots, automatically cleaning, re-usable. Counting Pool Cleaning: powerful water blasting flush in one-way. Needle Cleaning: Sample needle coating with special fluorine, blasting flush for interior, bubbling irrigation for exterior. Environment temp.: 15?~35?. Relative humidity: ≤85%. Atmospheric pr+essure: 86.0kpa ~ 106.0kpa. Power voltage: AC220V±22V. Power frequency: 50Hz±1Hz. Speed of test: 120 samples / hour. Dimension (length*width*height): 70cm*54cm*50cm. Package: One wooden case (84cm*61cm*69cm). Net Weight: 40KG. Gross weight: 66KG. Resolution of Screenshot: 640*480 320*240. LIS connection: Supported. 22” high resolution HP LCD, laser printer, directly print out report in Chinese or English.. OS: Windows 7.
Automatic dilution
High speed mechanical mixing
Separating with filtration of the collected larva and samples
Automatic adding liquid to counting pool, automatic sample loading, automatic imaging
Advised observation, analyzing of the results
Samples processed: Continuously processed for more than one sample
Automatic testing for occult blood on gaita, rotavirus and similar items
120 Samples testing per hour
Test Items: Test Contents
Routine gaita sample: General characteristic, microscopic analysis, larva and protozoa test
Occult blood on gaita: Immunity method, chemistry method
Virology test: Rota virus, Adenovirus, Coxsackie, hepatitis E, poliomyelitis
Bacteriology test: Spiral type bacterium in stomach, bacillary dysentery, enteropathogenic bacterium which is effecting infection on large intestine, typhoid and paratyphoid, cholera, salmonella bacterium which is causing to ulcer, intestine inflammation yersinia enterocolitica
?.High resolution imaging system
All procedure becomes true automatically, view angle changes automatically, focus adjustment is automatic.
?. Automatic Report
The user can select report types that are acceptable for public acts and including pictures and writings.
?.Automatic test
the errors or automatic alarms occur during operation is solved promptly by the system.
?.Counting pool
It has been designed acceptable to standardization of counting table and it has high sentitivity.
?.Microscopic analyses
Automatic,3D, user friendship and net picture.
?.Human-machine interface and easy work.
?.Conceivable system The user can start to operate after an easy training.
?.Sample probe cleaning No residue with Teflon technology. Long cleaning time with repeatable air and detergent foam cleaning
?. Colour Background Technology by using special colour background technology,outline of cell are identified more easily.
