Kanomax - Model PM -Large Particle Sensor Evaluating Kit
This sensor detects particles with a light scattering method, using one light emitter and two light receptors, and discriminates pollen from other particles with two factors: “scattered light intensity” and “degree of polarization”.
Most popular related searches
air quality monitoring
particle sensor
pollen counting
air purification
particle sizing
air conditioner
dust monitoring
air monitoring
dust monitoring sensor
particle detection
- Pollen discrimination and count, by “Degree of Polarization” – This sensor detects the particle with light scattering method, using one light emitter and two light receptors, and discriminates pollen from other particles with two factors “scattered light intensity” and “degree of polarization”.
- Built-in Suction Fan – Fan enables constant and larger sampling of air. Pollen count information can be made available without delay by taking advantage of the real time analysis.
- Built-in Heater prevents dew – Optical unit and circuit are fully covered with plastic case, and built-in heater keeps the sensor away from dew.
- Link to Ethernet system with purpose of monitoring at multiple location.
- Compact, Light, and Low Cost
- Air Purifier
- Air Quality Monitor
- Air Conditioner
- Ventilation
- Detectable particle size: approx. 15µm and larger
- Supply Voltage: 12VDC
- Operating Temperature: -10 to 45ºC
- Operating Humidity: 20 to 80% RH (no condensation)
- Dimensions: 71.4 x 76.4 x 36.7 mm
- Weight: 120g (approx)
