McLane - Model WTS-LV -Large Volume Water Transfer System
The Large Volume Water Transfer System (WTS-LV) is a large volume single-event sampler that collects suspended and dissolved particulate samples in situ into a 142mm membrane filter. The WTS-LV allows for a choice of pump size and filter porosity for a range of specimen collection. The Large Volume Water Transfer System (WTS-LV) is a large volume single-event sampler that collects suspended and dissolved particulate samples in situ into a 142mm membrane filter. The WTS-LV allows for a choice of pump size and filter porosity for a range of specimen collection. Collection targets include chlorophyll maximum, particulate trace metals, and phytoplankton.
The WTS-LV dynamic pump speed algorithm adjusts as material accumulates on the filter minimizing risk of a damaged sample and improving battery endurance. The modular filter holder is designed to evenly distribute collected material. A three-tiered filter holder option is also available.
The WTS-LV is available in four different configurations: Standard, Upright, Bore Hole, and Dual Filter Sampler. A high capacity upright WTS-LV model provides three times the battery life of the standard model. The Bore-Hole WTS-LV is designed to fit through a narrow opening such as a 30cm bore-hole. The WTS-LVDF features two vertical intake 142 mm filter holders to allow simultaneous filtering using two different porosities.
- OF SAMPLES: Single event sampler
- FILTER HOLDER: Black acetal/142 mm diameter
- DEPTH: Maximum depth 5,500m (standard model), 5,000m (upright model)
- TEMPERATURE
- RATING: 0° to 35°C
- POWER: 10Ahr battery pack (15,000 liters of seawater)
- 30Ahr battery pack on upright pump (36,000 liters of sea water)
