LUMINOR - Model RAINIER 6.0 -Light Commercial UV Water Disinfection
LUMINOR"s RAINIER6.0 model is feature laden and includes a discrete 254nm Teflon™-based UV sensor and integral 4-20mA output and solenoid ready capabilities. Manufactured from 316L stainless steel, these pressure vessels are designed & manufactured to ASME standards and are axial flow for optimal fluid flow. Without the need to drain the UV reactors, sleeve servicing is a simple operation. A bayonet style lamp connector allows for easy lamp change without the need for additional tools. For increased power density, RAINIER incorporates high quality low pressure, high-output (LP-HO) coated UV lamps offering a consistent output over their 10,000 hour life. Monitoring is provided through an integral LED display which in addition to the UV output, displays remaining lamp life, total running hours, audible & visual lamp failure and remote-on. Packaged with constant current electronic ballasts and housed in a splash-proof case, flow rates of 100 & 160 lpm (25 & 40 gpm), in both 120V or 230V applications, are offered in this product line.
If microbiological protection is required for your commercial/industrial application, then LUMINOR has the solution in the Rainier6.0 series of ultraviolet disinfection systems.
RAINIER6.0 includes a discrete 254nm Teflon™ based UV sensor to continuously monitor the UV output produced by the system. Displayed on the LED screen in either “% UV Intensity” or “mW/cm2 ", RAINIER6.0 provides the information that these demanding commercial systems require.
Constructed with highly polished 316L stainless steel reactors and industrial grade enclosures, RAINIER6.0 uses proven low pressure highoutput (LP-HO) lamp technology to control microbiological (bacteria & virus) issues in water (or other viscous fluids), including E.coli, Cryptosporidium and Giardia lamblia.
Covering a wide variety of applications in both regulated and unregulated markets, RAINIER6.0 offers environmentally friendly disinfection at lower capital and operating costs than traditional disinfection solutions.
- Discrete 254nm TeflonTM based UV sensor for continuous UV monitoring with the added benefit of anti-fouling materials
- Modular control panel with LED display for UV output, remaining lamp life, total running hours, audible & visual lamp failure, remote on and solenoid ready
- Axial flow, 316L stainless steel, polished reactors
- Designed & manufactured to ASME pressure vessel standards
- Flow rates stated at 95% UVT at a dose of 30mJ/cm2
- User friendly bayonet style lamp connector (quick ¼ turn removal with no extra tools needed)
- True gland seal retaining nut with positive stop
- Reliable, industry proven low pressure high-output (LP-HO) coated UV lamps with ceramic bases for durability and a 10,000 hour life
- Constant current electronic ballast/controller (one for all systems) in a splashproof case with audible and visual lamp failure indicators
