Pro-Dig USA - Model L5K -Lightweight Drive Head with Bail for Drilling Applications
FromPRO-DIG, LLC
The L5K Lightweight Drivehead with Bail is a specialized product in Pro-Dig USA's line of drilling equipment. This drive head is from the L Series, characterized by its lightweight design, making it suitable for use in confined spaces such as basements or situations requiring overhead load capabilities. It features a premium Parker Hannifin hydraulic motor and a light portable planetary gearbox. The drive head also includes a single piece shaft/gear carrier that is enhanced with high-quality taper roller bearings on either side, ensuring its capability to handle high radial loads. The unit is compatible with a flow range of 5-16 GPM and can withstand a maximum pressure of 2500 PSI. It offers field serviceability and is backed by a lifetime shaft pullout warranty, making it a reliable choice for screw pile applications with an option of a load control valve. Manufactured and serviced in the USA, this tool exemplifies quality and efficiency in demanding environments.Most popular related searches
- Light Portable Planetary Gearbox
- Premium Quality Parker Hannifin Hydraulic Motor
- High Quality Taper Roller Bearings
- Single Piece Shaft/Gear Carrier
- Lifetime Shaft Pullout Warranty
- Load Control Valve Available for Screw Pile Applications
- Ideal for use as a Handheld Drill in basement or load overhead applications
- Single Piece Shaft/Gear Carrier allows Taper Roller Bearings positioned either side of gear carrier resulting in High Radial Load Capability
- Field Serviceable
- Manufactured and Serviced in the USA
- Motor Mount: SAE “A” 2 Bolt
- Motor: 160cc
- Flow Range: 5-16 GPM (US)
- Max Pressure: 2500 PSI
- Output Shafts: 2″ Hex
- Unit Weight: 132 lbs
