ARP - Model RS-L10 Series -Louver Damper Valve
FromARP Industry srl
The louver damper can be single or multiple blade operated by an external linkage. The blade movement can be opposed or parallel. Opposed blade movement is the most effective choice for modulating service. Air sealing with harmonic metal seal can be supplied on request. Dimensions of the duct and drilling of the flange are made to customer specifications.
Most popular related searches
louver damper valve
damper
valve actuator
electric actuator
pneumatic actuator
gaskets
actuated valve
EN standard
- Size range upon request
- Max temperature 200 °C
- Isolating or modulating service
- Designed for 50 mm insulation
- CE marking
Operating conditions
- Design temperature –40°C ÷ 200°C
- Design pressure –0,1 barg ÷ +0,5 barg
Applicable standards
- Design EN 593, EN 12516, ASME B16.34
- Flanges according to customer request
- Testing EN12266, ANSI/FCI70-2
Ends connections
- Bolted flanges
- Butt welded
Blade seals options
- No seal – Geometric tightness 96%
- Metal to metal – FCI 70-2 max tightness class II
- Harmonic steel lamellas – FCI 70-2 max tightness class III
- Soft sealing – FCI 70-2 max tightness class III
Valve actuation
- Top flange connections: EN ISO 5210, EN ISO 5211
Actuator types:
- Manual with lever or handwheel
- EN 15714-2 Electric actuators
- EN 15714-3 Pneumatic actuators
Shaft seals options
- No seal
- Graphite braid packing
- Braid packing with lantern ring and air sealing
- Flat elastomeric gasket
Materials
- Carbon steels
- CORTEN A
- Wear resistant steels
- Ferritic, austenitic and duplex stailness steels
Bearing options
- One external bearing
- Double shaft with two external bearings
