Transducer - Model RTS Series -Low Capacity (Inch-Ounce) Reaction Torque Sensor

The RTS Series torque sensors were designed to fill the need for accurate torque measurements below 62.5 in lbs without giving up stiffness or sensitivity to forces from other directions. They are manufactured from sensor quality aluminum and anodized for long term durability. Bonded foil strain gages and materials of the highest quality are installed assuring high reliability. The four bolt hole pattern with the use of our O.D. or I.D. pilots on either end allows simple adaptation to any application.
