Bac-ValvesModel PQR-i CLASS 150-300, NPS 1/2 -Low Temperature Floating Ball Valve

SHARE

Reduced bore, one piece body, floating ball, high low emission double stuffing box, relief seats, extended bonnet (vapor space) , anti-static device, fire safe, pressure balance hole in ball, blow-out proof stem.

Most popular related searches
  • High performance low emission double stuffing box.Internal wetted part are in acc. to NACE Standard MR0 103.
  • API 6D
  • Design    ISO 17292
  • End    Flanges acc. to: ASME B16.5 RF
  • Face to face    ASME B16.10 long pattern
  • Top flange  ISO 5211
  • Testings    EN 12266/1
  • Fire safe tested  ISO 10497 and API 607
