MDSJ - Tray Wet Scrubber

Depending on application requirements, several tier tray types and one or more tiers can be included in the mdsj tray. Tray Wet Scrubber, recycled liquids containing 2% solids can be used

During operation, the dirty gas enters the bottom of the scrubber and passes through the holes in the tray. The washing liquid enters the upper contact stage and flows through the tray. It absorbs gas, dust retention and liquid where special gas/liquid mixture occurs. The cleaned gas then passes through the demister and above the unit to atmosphere.

MDSJ Turbulent contact tray Tray Wet Scrubbers can be made from carbon steel, stainless steel, special alloys and plastics. There are units with capacities ranging from 1000 to 400 thousand m3.

MDSJ tray Tray Wet Scrubber, scrubber is a versatile low pressure Tray Wet Scrubber suitable for a wide range of applications with highly efficient dust capture.

Mdsj tray scrubber is also suitable for the absorption of gases and vapors such as SO2, HF, HCI, NH3 and CI2 and for SO2 removal.

The Tray Wet Scrubber can be equipped with a perforated turbulent contact tray or a controlled tray.

The perforated type tray contains a large number of holes. The controlled tray is similar to the regular tray scrubber but has special guides placed over each hole. The diverters increase the dust collection efficiency because the dust acts directly on the submerged target, which is then washed away by the flowing liquid.

Depending on application requirements, several tier tray types and one or more tiers can be included in the mdsj tray. The scrubber can use recycled liquids containing 2% solids. During operation, the dirty gas enters the bottom of the scrubber and passes through the holes in the tray.

The Tray Wet Scrubber fluid enters the upper contact stage and flows through the tray.

The gas absorbs dust and liquid, where a special gas/liquid mixture occurs.

The cleaned gas then passes through the demister and above the unit to atmosphere.

MDSJ Turbulent contact tray Tray Wet Scrubbers can be made from carbon steel, stainless steel, special alloys and plastics. There are units with capacities ranging from 1000 to 400 thousand m3.

• Absorption from SO2, NH3, HC1, HF and CI2′ gases.
• Brushing and cooling in metallurgical acid plants.
• Municipal sewage sludge. gas cleaning in incinerators.
• fertilizer factories
• Chlorine plants, drying and cooling plants, wood industry

As the gas entering the tower moves upwards, it passes through a perforated tray where it interacts with the orifice fluid on the plate surface. A certain size and amount of holes cause the gas to bubble strongly in the liquid, increasing the gas/liquid contact time and contact surface. The number of trays, irrigation rate and chemical requirement, cleaning ability are determined by the type of contamination and the degree of cleaning efficiency.

Before being thrown into the atmosphere, the cleaned gas passes through the fog remover on the tower and the mists are caught here

MDSJ ENVIRONTEC table applications Mdsj table wet scrubber scrubber can generally be used in any gas suction suction lines, especially at points containing particles. In addition, mdsj Inventi Tray Wet Scrubbers are specifically designed to remove particulate matter of 3 microns and larger and fumes and gases that may be present with a gaseous pollutant.

MDSJ ENVIRONTEC table wet scrubber scrubbers have High Efficiency, Low Cost

High efficiency:– Depending on proper Sizing of the unit, choice of tray number, and water to gas ratio, 97 percent or higher yields can be achieved. Units with MDSJ trays contain 2, or 5 trays, but all wet scrubbers with mdsj trays may require custom design to meet the specific requirements of each application.

Low operating cost – MDSJ Inventi design low velocity low pressure gas passages minimizes water consumption and can completely eliminate chemical addition. Also, power consumption is reduced, as a recirculation system is usually not required.

MDSJ ENVIRONTEC WET Tray Wet Scrubbers are designed for a wide variety of applications. Different gases can be easily realized and regulated in a single unit rather than in multiple stages.

Material durability is very long by choosing materials with high resistance to mixed acids according to the application area

To select an mdsj wet scrubber for a particular application, the operating factors must be well known, the volume of gas absorbed, the type of pollutant present, the efficiency.

At this point, mdsj authorized engineers assist in the selection of auxiliary equipment, pumps, fans and chemical feeding systems to create a complete system as well as system size.
