Inciner8 - Model I8-M40 -Medical Incinerator
Our i8-M40 is a simple and effective medical incinerator. It was deisgned for small clinics, dental practices or small medical facilities where waste streams are quite low. The top-loading design means liquids are well contained within this system during incineration. Featuring inbuilt afterburners, the i8-M40 ensures harmful emissions are eradicated with ease. The i8-M40 is a medium capacity model from our range of specialist "M" incinerators. The addition of an advanced CE2-VFD control panel, I.D. fan and increased insulation improves performance and provides all-round suitability for many different types of medical, clinical, pharmaceutical and hazardous waste streams.
- Enhanced Coretex insulation
- Multi-zone temperature control
- Mobile options available
- CE2-VFD Advanced control panel
- Tertiary air control
- Medical Laboratories
- Dental / Cosmetic Clinics
- Blood Banks / Collection
- < 250 Bed Medical Facilities
- Medical Facilities
All our incinerators are hand-built in the UK by time-served welders and fabricators. Our award-winning design team are always on hand to offer their advice and technical know-how to ensure we get your project off the ground without delay.
We can also assist you in the preparation for your planning or permit application where required.
Operational Specifications
- Combustion Chamber Volume (m3): 0.36m3
- Burn Rate*: up to 30kg per hour
- Average Fuel Consumption: 9 - 11 ltrs p/h
- Operational Temperature: > 850°C
- Gas Retention in Secondary Chamber: 2 secs
- Temperature Monitoring: Yes
- Average ash residue (%): 3%
- Thermostatic Device: Yes
Physical specifications
- External Length (mm): 1240mm
- External Width (mm): 920mm
- External Height (mm): 4400mm
- Door Size (mm): 0.56 x 0.56
- Shipping Weight: 1520kg
For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additonal accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
