PSG All-Flo - Model A075 -Metal Diaphragm Pump

Air Inlet : 1/4" FNPT. Liquid Inlet: 3/4". Liquid Discharge: 3/4". Connection Type: FNPT/FBSPT (Threaded). Max Suction Lift Capability: 15 ft-H2O (4.6 m-H2O), Dry. 31 ft-H2O (9.4 m-H2O) Wet. Max Flow Rate: 15 gpm (56.8 lpm). Max Pressure: 120 psi (8.2 bar). Max Diameter Solids: 1/8" (3.2 mm). Displacement Per Stroke: 0.03 gal (0.10 L).
