PSG All-Flo - Model A100 -Metal Diaphragm Pump

Air Inlet: 1/4" FNPT. Liquid Inlet: 1". Liquid Discharge: 1". Connection Type: FNPT/FBSPT (Threaded). Max Suction Lift Capability: 17 ft-H2O (5.2 m-H2O), Dry : 30 ft-H2O (9.1 m-H2O) Wet. Max Flow Rate. : 48 gpm (182 lpm). Max Pressure: 120 psi (8.2 bar). Max Diameter Solids: 1/4" (6.4 mm). Displacement Per Stroke: 0.07 gal (0.28 L).
