Pall Ring - Metallic Packing Media
A mechanically robust packing media, ideal for various separation and absorption applications at atmospheric pressure and under vacuum, where a low pressure drop is critical.
Most popular related searches
metal structured packing
metal pall ring
distillation column
tower packing
packing pall ring
fouling
stripping tower
cooling tower
distillation tower
packed tower
THE PALL RING HAS SIMILAR CYLINDRICAL DIMENSIONS TO THE RASCHIG RING.
It has two rows of punched out holes with fingers or webs turned into the centre of the cylinder, which significantly increases the performance of the packing.
Metal Pall Rings can be manufactured in a a range of metals such as grade 304, 316, or 430 Stainless Steel, Carbon Steel, Copper or special alloys.
ADDITIONAL INFORMATIONCAPACITY VS PRESSURE DROP- High loading & throughput / low pressure drop;
- Good liquid / gas distribution and high mass transfer efficiency.
- Easily wettable;
- High resistance to fouling;
- High Temperature.
- High temperature applications;
- Mechanically robust, lesser probability of breakage, suitable for deeper beds.
KEY BENEFITS
- Capacity vs Pressure Drop
- Versatility
- Mechanical Strength
- Large range of different grades of steel available
- Available in copper and other special alloys also
- No minimum order quantities
- Full quality and material certification available
- High resistance to fouling
TYPICAL APPLICATIONS
- Suitable for high temperature applications
- H2S, NH3 & SO2 Absorption & Stripping
- Steam Stripping
- Quench towers
- Direct contact cooling
- Reaction towers
- Distillation columns
